NIGHT ARROW PRO

Thermal Scope

LIIR

Patent NO. 202023103202. LIIR, an exclusive patented design by CONOTECH. It ensures perfect alignment of the laser and infrared axes, offering superior precision and reliability in operation.

Highly sensitive thermal imaging sensor

The 12μm thermal imaging sensor with <15mK NETD offers sharp, richly contrasted images. Compared with 17μm sensor, it has a smaller FOV, looks sharper and more detailed enabling better object identification capabilities.

Easier operation

Night Arrow has a unique wheel design. The rotating wheel operates more precisely and effectively. By rotating the wheel, Night Arrow not only enters the upper/next flat visual menu but also zooms in/out when observing.

Recoil activated video

Recoil activated video, pre-recording function initiates upon recoil detection, capturing the 10s span before and after your shot.

Ballistic calculator

The integrated ballistics calculator is designed to precisely determine the projectile’s path and point of impact by utilizing predefined parameters.

User friendly silent controls

Night Arrow is easily operated by using the two function buttons (MENU and REC), the unique wheel and a controller. With easy access to all controls, Night Arrow is simple to use for both left and right-hand users. In addition, Night Arrow features a silent shutter, controller and buttons so you can hunt without disturbing your surroundings.

12 hours operating time

Night Arrow supports an external removable battery to increase your hunting duration to more than 12 hours.

Built-in audio & video recording

Specifications

Night Arrow Pro

Model
NAR PRO 225LRF
Main Characteristics
Detector
Uncooled Vox
Detector resolution
256×192
Frame rate
50Hz
Pixel
12μm
Spectral range
8-14μm
NETD
<20mk
Optical Characteristics
Objective lens
25mm
Magnification
3.7×
FOV (H×V), m@100m
12.2×9.3
Functions
Zoom
1×/2×/3×/4×
Palettes
Multiple
Firmware update via APP
Yes
Display
Type
OLED
Resolution
1920×1080
External video
WIFI
Power Supply
Battery
2×18650 (Built-in battery) + 1×18500 (External battery)
External power supply
5V-2A, 9V-2A (USB-C)
Operating time (at t=22°C)
16h
Physical Characteristics
Weight
900g
Dimension
80×85×407mm
Environmental Compatibility
Ingress protection rating
IP67
Operating temperature
-20℃~+50℃
Storage temperature
-40℃~+70℃
Shock resistance
7000J
Laser Rangefinder
Safety class
1
Measuring range
5-1200m
Measurement accuracy
± 1m

Night Arrow Pro

SKU N/A Category
ModelNAR PRO 225LRF
Main Characteristics
DetectorUncooled Vox
Detector resolution256×192
Frame rate50Hz
Pixel12μm
Spectral range8-14μm
NETD<20mk
Optical Characteristics
Objective lens25mm
Magnification3.7×
FOV (H×V), m@100m12.2×9.3
Functions
Zoom1×/2×/3×/4×
PalettesMultiple
Firmware update via APPYes
Display
TypeOLED
Resolution1920×1080
External videoWIFI
Power Supply
Battery2×18650 (Built-in battery) + 1×18500 (External battery)
External power supply5V-2A, 9V-2A (USB-C)
Operating time (at t=22°C)16h
Physical Characteristics
Weight900g
Dimension80×85×407mm
Environmental Compatibility
Ingress protection ratingIP67
Operating temperature-20℃~+50℃
Storage temperature-40℃~+70℃
Shock resistance7000J
Laser Rangefinder
Safety class1
Measuring range5-1200m
Measurement accuracy± 1m
